WAGO PCT-221 1 In 1 Out Connector
The WAGO PCT-221 1 In 1 Out Connector is a compact, reliable push-wire connector designed for quick and secure cable connections in electrical installations. Known for its transparent housing and easy-to-operate lever, the PCT-221 series allows fast wiring without the need for twisting or soldering. This specific version supports 1 input and 1 output wire, making it ideal for simple inline splicing or extending single wires. It’s suitable for solid, stranded, or fine-stranded conductors, and the clear housing lets you visually check proper wire insertion. Whether used in home wiring, lighting fixtures, or junction boxes, this WAGO connector saves time, ensures a solid connection, and improves safety and maintenance.
Key Features
Compact Design: Space-saving for tight enclosures and junction boxes.
Lever-Operated: Open/close clamp lever for tool-free wire insertion and removal.
Universal Compatibility: Accepts solid, stranded, and fine-stranded wires.
Transparent Housing: Easy visual inspection of wire seating.
Reusable: Open the lever to rewire or adjust connections anytime.
Reliable Contact: Spring mechanism ensures secure, vibration-resistant contact.
Specifications
Model: WAGO PCT-221 (1 In 1 Out).
Connection: Push-in, lever type.
Number of Ports: 1 input, 1 output.
Wire Size Range:
Solid: 0.2–4 mm²
Stranded: 0.2–4 mm²
Fine-stranded: 0.14–4 mm²
Rated Voltage: Up to 450 V.
Rated Current: Up to 32 A.
Temperature Rating: -40 °C to +85 °C.
Housing Material: Transparent polycarbonate.
Certifications: CE, UL, VDE (varies by region).
Applications
Electrical splicing in residential and commercial wiring.
Extending or repairing single wire runs.
Lighting fixtures, ceiling fans, and wall switches.
Prototyping and test setups in labs.
Anywhere fast, secure inline connections are needed.
